tempmate-S2-TH Single Use Temperature and Humidity Data Logger


tempmate-S2-TH Single Use Temperature and Humidity Data Logger

Cadmus is the latest addition to the Signatrol data logger and alarming system range. It's a battery powered, WIFI enabled logger which, when used with our Ratifi-Cloud based software package, provides professional data logging records combined with real time alarming facilities.

application examples

  • Environmental Monitoring
  • Humidity Sensitve Goods In Transit
  • Pharmaceutical Transportation

specification

  • Log Duration : 180 Days
  • Recording Option : Single Use
  • Shelf Life : 24 months from production. Minimum 18 months on delivery. Please contact us if longer shelf life is required
  • Waterproof : No, IP54 - ventilation required for humidity measurement
  • Measuring Range : -30°C to +70°C (-22°F to +158°F) 0 to 100%RH
  • Accuracy : ±0.3°C / ±3%RH
  • Resolution : 0.1°C / 0.1%RH
  • Sample Rate : 10 minutes standard (others available on request)
  • Number of Readings Stored : 32,000
  • Reusable When Memory Full : No
  • Alarm Type : Single Event / Cumulative Alarm. Alarm setpoints specified at the time of order if required. If alarm setpoints are not specified, no alarms will be generated.
  • Weight : 30g
  • Dimensions : 93mm (L) x 47mm (W) x 8mm (H)
  • Warranty : 1 Year
  • Response Time : T90: 3 minutes in air

To view the full specification please download the datasheet below.

description

TEMPMATE-S2-TH SINGLE USE USB TEMPERATURE & HUMIDITY DATA LOGGER WITH LCD

The tempmate-S2-TH is now here! It is still small, light, in a food safe hard plastic case and now with liquid crystal display. Features include:

  • Accuracy ±0.3°C ±3%RH.
  • Long run time, 180 days (depending on sample rate).
  • Massive data capacity of 32,000 measurements.
  • Calibration validation certificate is stored on the data logger and can be downloaded when needed.
  • Made from recycled plastics.
  • Data can be uploaded to the tempmate cloud and can be accessed and downloaded from anywhere in the world.
  • The tempmate-S2-TH can be customised to your requirements within 48 hours.

The tempmate-S2-TH single use USB temperature and relative humidity data logger is ideal for monitoring the temperature and humidity of cold supply chain shipments that are in transit. Recordings are started by pressing the start button. The data logger is then placed inside the carton and despatched. At the receiving end, the temperature data logger is taken from the package and removed from the protective wrapper. It is placed into the USB slot on a computer and the PDF file is available as if it was on a memory stick. No interface cables or software are required. Compliant to BS EN 12830.

Labelling per IATA's dangerous goods regulations is not required for tempmate-S2-TH temperature data loggers.

tempmate-S2-TH single use USB temperature data loggers are available ex-stock and can be dispatched the same working day if the order is received by 12 noon.



select your product option

Quantity
Single Use USB Temperature & Humidity Data Logger With LCD £44.00 Ex.VAT
